U.S. Navy Ships in WWII Dazzle Camouflage 1944-1945

Auxiliary Ships

View by Design Number

Seaplane Tenders

View by Design Number

for AV-7

Design 15Ax

for AV-7

Design Number Silhouette Ships Wearing Design
for AV-7
Measure 32
Currituck (AV-7)Norton Sound (AV-11)
Drawing

The drawing for Design 12Ax for Currituck class seaplane tenders dated June 14, 1944. The Measure 32 vertical colors were dull black (BK), ocean gray (5-O) and light gray (5-L) and the deck was all deck blue (20-B).

This is the only version of Design 15Ax that has been found.

Original drawing source: NARA 80-G-174551 and 80-G-174552.
